Usage

This machine can be used to change with the various demands of the form of the package of yam,especially suitable for rewinding requirement of the sprinning workshop,the pagoda is bobbin and parallel bobbin pour into the corresponding cone shape for dyeing.

Main Technical Specifications and Parameters

Type:Single spindle

Number of spindle:60 spindles

Machinable yarn count:Ne3~Ne142（Nm5-Nm240）

Supply bobbin dimension:The maximum ￠240mm

Winding bobbin maximum winding diameter: ￠320mm

The winding speed:the highest speed of 2000 m/min

Connecting method:Air twisting connection;spray wet air twisting connection

Mpa Power:20kw

Dimension of machine(length×width×height):23300×1900×3000(mm)
